Hoffman A16H1208SSLP Stainless Steel Enclosure NEMA Type 4X 16" x 12" x 8"
Description
This listing is for a Hoffman Nvent Electrical Enclosure.
Model: A16H1208SSLP
Specifications:
Brand: Hoffman / Nvent
Condition: New in box
Type: Electrical Enclosure
Seams continuously welded and ground smooth
Seamless foam-in-place gasket
Rolled lip around three sides of door
Stainless steel door clamp assembly
Hasp and staple for padlocking
Door removed by pulling stainless steel continuous hinge pin
Data pocket is high-impact thermoplastic
Height: 16 in / 406 mm
Width: 12 in / 305 mm
Depth: 8 in / 203 mm
Thickness: 14 ga / 1.98 mm
Panel Size: 13.00 x 9.00 in / 330 x 229 mm
Steel Panel: A16P12
Stainless Steel Type: 304
Data Pocket: Small
Protection Rating: NEMA Type 12; NEMA Type 13; NEMA Type 4; NEMA Type 4X; IP66
Material: Stainless Steel 304
Finish: Brushed #4
Color: Unpainted
Thickness: 14 ga / 1.98 mm
Panel Size: 13.00 x 9.00 in / 330 x 229 mm
Steel Panel: A16P12
Stainless Steel Type: 304
Data Pocket: Small
Conductive Steel Panel: A16P12G
Stainless Steel Panel: A16P12SS6
Clamp Quantity: 4
Weight: 23.6 lb
This item is exactly as pictured.
